MILIO 50W Solar Street Light
MILIO丨50W Solar Street Light
MILIO丨50W Solar Street Light
The MILIO series is a premium, compact solar street light specifically engineered for use with lower light poles ranging from 3 to 6 meters in height. Designed with durability and performance in mind, it features a robust die-cast aluminum housing for superior heat dissipation and weather resistance. Powered by an advanced MPPT solar controller, MILIO ensures optimal energy conversion and battery charging efficiency.
The integrated A-grade LiFePO4 battery guarantees long-lasting, stable performance with extended lifespan. Ideal for urban pathways, residential streets, and parks, garden lighting etc, MILIO combines cutting-edge technology with a sleek, compact design for reliable outdoor lighting.
Key Componente & Advantages
MPPT Charge Controller
maximizes energy efficiency ensuring longer battery life and consistent illumination without blackout。
High Brightness Led
High brightness led enhances visibility and safety while providing energy-efficient
Robust Design
Robust design of light fixture provides superior durability, corrosion resistance, and heat dissipation.
High Charging Efficiency
A high-efficiency solar controller maximizes energy conversion, ensuring rapid and reliable battery charging.
Compact Design
An integrated design enhances reliability and simplifies installation and maintenance with asthetical appearance.
Bright Performance
High-brightness LED chips provide superior illumination, enhancing visibility and energy efficiency.
Main Specification
Model NO.
MILIO AIO-50WM
MILIO AIO-30WM
LED Power
50W max
30W max
Luminous Flux
8,500lm
5,100lm
CCT
3000K~6000K
●
Beam Angle
Type II/III
●
LiFePO4 Battery
12.8V 30AH
12.8V 12AH
Battery Lifetime
2000 cycles
●
Solar Panel
60W 18V Mono
40W 18V Mono
Solar Controller
MPPT
●
Motion Sensor
PIR / Microwave
●
Remote Control
Yes
●
Dimension
900*380*88mm
740*350*85mm
Operating Temp.
-20℃ ~+60℃
●
IP Rating
IP66
●
Pole Diameter
60mm
●
Pole Height
5~8 meters
3~5 meters
Warranty
3 Years
●
You May Ask
Can all-in-one solar light connect with 220V AC?
ZAIN all-in-one solar light is available in hybrid solution(DC+AC), adopting hybrid charge controller to succeed in this solution.
What's the type of sensor for all in one?
Sensor available in PIR or Microwave sensor, we suggest PIR sensor for pole height below 7-8 meters, Microwave sensor for pole height over 8 meters.
What is all-in-one solar street light?
All-in-one solar street light integrated all components in one fixture, including LED light, battery, charge controller, solar panel, easy for installation, no need wiring or extra brackets.
What's the material of all-in-one solar street light?
SunRise adopts die-cast aluminum to build a robust lighting fixture for all the models of solar street light
What're the benefits of ZAIN battery box outside the case?
The separated battery box is good for heat insulation, easy to disassemble and maintain, and has good IP protection.
What is the default working mode of ZAIN solar street light
2h 100%+4h（30% + 70% sensor）+7h（20% +50% sensor） , it can be modified easily by remote control according to customers' requirement.
What‘s the adjustable range of LED board ?
The adjustment range is +30° ~ -10°, this is to ensure the lighting hits the road with higher use efficiency without wasting.
What is the diameter of the pole for zain AIO solar light?
There are two standard sizes as 76mm and 60mm. Considering the load-bearing problem, we recommend using 60mm/76mm for power below 100w(2 modules or 3 modules ). and Use 76mm for high power models.
Can we customized the light fixture color ?
Factory standard RAL code is 7016, customized light fixture color can be accepted with MOQ 100PCS
Can i use a AC power adapter to charge batteries?
We can provide a AC charger to charge the solar light in case the light is put in warehouse too long time.
What is the maximum battery capacity of ZAIN ?
The Max battery capacity is 25.6V 1536WH, all the light configurations can be customized according to requirements.
