Linear Moon Tunnel Light

Specifications

Feature summary — Power

100–330 W

Parameter table — Power

10–330 W, depending on model

Feature summary — Max output

56,100 lm

Feature summary — Efficacy

up to 170 lm/W with clear glass

Parameter table — Efficacy

110–120 lm/W

Feature summary — CCT

1800K–6500K

Parameter table — CCT

3000 / 4000 / 5000 / 5700K

Feature summary — Lifetime

>100,000 h

Protection

IP66; feature summary up to IK09

Power factor

≥0.95 for UNI-TNF3-1; ≥0.90 for remaining models

Input / CRI

AC100–277 V, 50/60 Hz / 70 or 80

Working / humidity / storage

−40°C to 45°C / 10–90% / −40°C to 65°C

Housing

die-cast + extruded aluminum + tempered glass

Construction / mounting

tempered glass + PMMA + die-cast / wall or bracket

Optics

Type I UNI-876 / UNI-909; Type II UNI-850

Certifications

CE / RoHS

Applications
