Solar Lighting / HeXa Series
HeXa Vertical Solar Panel
Six slim mono-crystalline panels wrap your pole — 360° all-day charging, wind-resistant to 160 km/h.
- Models
- Q140 (140W) · Q200 (200W)
- Cell efficiency
- 22.5 % MONO
- Wind resistance
- Up to 160 km/h
- Pole diameter
- 75 – 120 mm
- Protection
- IP65 · CE · RoHS
- Warranty
- 5 yrs / 20+ yr life
Two modular hexagonal models — 140W and 200W.
High-efficiency monocrystalline cells.
Vertical 360° solar collection around the pole.
Outdoor rated with 5-yr warranty, 20+ yr life.
Modular hexagonal geometry
- Six slim mono-crystalline panels per module
- Hexagonal cylinder wraps the pole
- Field-assembled — modular service & swap
- 360° all-day charging from any sun angle
Pole diameter compatibility
- Fits standard poles 75 – 120 mm diameter
- 2.5 mm² cable with MC4 connectors
- 18V / 36V output options
- Drop-in replacement for top-mounted flat panels
Wind & outdoor durability
- Wind-resistant up to 160 km/h
- Working range −30 °C to +70 °C
- IP65 sealed, snow & dust shedding
- CE / RoHS certified for outdoor sites
Pairs with Vertical Solar Cylinder
- HeXa = exact module spec
- Vertical Solar Cylinder = system concept
- Use together for smart-pole rollouts
- Custom configurations for project loads
Q140 vs Q200
Same platform, two power tiers. Both fit poles 75–120 mm.
- Vmp
- 18 V / 36 V
- Imp
- 7.78 A / 3.88 A
- Dimensions
- 1560 × 228 × 200 mm
- Vmp
- 18 V / 36 V
- Imp
- 11.1 A / 5.56 A
- Dimensions
- 2060 × 228 × 200 mm
- Cell type
- Monocrystalline
- Cell efficiency
- 22.5 %
- Operating temperature
- −30 °C to +70 °C
- Pole diameter
- 75 – 120 mm
- Wind resistance
- Up to 160 km/h
- Cable / connector
- 2.5 mm² with MC4
- Protection rating
- IP65
- Certifications
- CE · RoHS · IP65
- Warranty
- 5 years
- Operational life
- > 20 years
Where HeXa fits
Built for pole-mounted lighting, smart-city and off-grid infrastructure.
HeXa — exact module specs
Q140 and Q200 hexagonal modular panels with confirmed electrical, mechanical and environmental data.
- • Wattage, voltage, current
- • Dimensions & pole compatibility
- • Certifications & warranty
Vertical Solar Cylinder — concept
The system-level concept page covering pole-wrap geometry, applications and how vertical solar integrates with smart poles.
