LED Lighting / Street Lights
Beluga Street Light
Red Dot Design, Built to Last
- Feature summary — power
- 15–330 W
- Feature summary — max output
- 54,450 lm
- Feature summary — efficacy
- up to 165 lm/W
- Feature summary — CCT
- 1800K–6500K
- Feature summary — protection
- IP66, up to IK09
- Feature summary — lifespan
- >100,000 hours
Specifications
- Feature summary — power
- 15–330 W
- Feature summary — max output
- 54,450 lm
- Feature summary — efficacy
- up to 165 lm/W
- Feature summary — CCT
- 1800K–6500K
- Feature summary — protection
- IP66, up to IK09
- Feature summary — lifespan
- >100,000 hours
- Parameter table — life
- 100,000 hrs
- Parameter table — LED
- Osram / Lumileds
- Parameter table — CCT
- 3000±300K / 4000±300K / 5000±300K / 5700±500K / 6500±500K
- Parameter table — efficacy options
- 125 / 135 / 150 lm/W at 4000K, Ta=25°C
- Parameter table — CRI
- 70
- Mounting
- Side entry or post top, ±20°, Φ42/60/76 mm spigots
- Optics
- Type I (UNI-691); Type II (UNI-540); Type II (UNI-618); Type III (UNI-712)
- Certifications & reports
- CE / CB / ENEC / ENEC+ / Darksky / EPD / RoHs / IP66 / IK09 / D4i
Feature summary and parameter table values are shown separately where published values differ.
Applications
HighwaysArterialSecondaryBranch roadsMajor vehicle lanes
Parameter table
Published model range
| Model | Power | Dimensions | Net weight |
|---|---|---|---|
| UNI-STB1-1 | 45 W | 573×220×131 mm | 3.6±0.2 kg |
| UNI-STB1-2 | 60 W | 664×251×132 mm | 4.7±0.2 kg |
| UNI-STB1-3 | 90 W | 664×251×132 mm | 5.0±0.2 kg |
| UNI-STB1-4 | 120 W | 740×285×132 mm | 6.2±0.2 kg |
| UNI-STB1-5 | 90 W | 740×285×132 mm | 5.8±0 kg |
| UNI-STB1-6 | 150 W | 760×327×136 mm | 7.8±0.2 kg |
| UNI-STB1-7 | 200 W | 760×327×136 mm | 8.5±0.2 kg |
| UNI-STB1-8 | 200 W | 920×383×131 mm | 11.0±0.2 kg |
| UNI-STB1-9 | 300 W | 920×383×131 mm | 12.5±0.2 kg |
Feature summary
Key features
- Tempered glass, PMMA lens, and anti-corrosion die-cast aluminum
- Tool-free maintenance with detachable driver chamber
- NEMA and Zhaga smart-ready
- Side-entry or post-top mounting
